ScreenTinker — Open-Source, Self-Hosted Digital Signage Software

Live demo · API reference · Self-hosting guide · Discord

ScreenTinker is a free, open-source digital signage CMS you can self-host on your own server — or run in our managed cloud. Manage TVs, video walls, and kiosks across multiple locations from one dashboard, with remote control, scheduling, playlists, and analytics. Built for retail, QSR menu boards, offices, lobbies, education, and any environment where you need centralized control over remote screens. Multi-tenant, MIT-licensed, single-developer maintained with direct contact access.

Runs on any screen — Android TV, Fire TV, Samsung Tizen, LG webOS, Amazon Vega OS, Raspberry Pi, Windows, ChromeOS, or any web browser. No per-device player licence, no hardware lock-in.

Why self-host? Keep your content and data on your own infrastructure, avoid per-screen SaaS fees, run air-gapped on a private LAN, and read or fork the source. Set SELF_HOSTED=true and a $5 VPS drives hundreds of screens.

Hosted version: screentinker.com — free tier available, no credit card required. Guides: What is digital signage? · Open-source digital signage · Self-hosting guide Community: Discord

Features

• Playlists — first-class playlist objects: create, reorder, set per-item duration, share one playlist across multiple displays; draft/publish workflow with revert-to-published
• Device groups — organize displays into groups, assign a playlist to an entire group, send bulk commands (reboot, screen on/off, launch, update, shutdown), schedule content group-wide
• Multi-zone layouts — split screens into zones with drag-and-drop editor; 7 built-in templates (fullscreen, split, L-bar, PiP, grid)
• Video walls — combine multiple displays into one screen with bezel compensation, device rotation, and leader-based sync
• Remote control — live view, touch injection, key input, power on/off
• Scheduling — visual weekly calendar with recurrence rules (daily/weekly/monthly), priority-based conflict resolution, both device-level and group-level schedules (device-level overrides win over group-level), timezone support
• Widgets — clocks, weather, RSS tickers, text/HTML, webpages, social feeds, and Directory Board (scrolling lobby tenant/room/staff directories with dark/light themes, category management, and anti-burn-in motion)
• Kiosk mode — interactive touchscreen interfaces
• Proof-of-play — per-content and per-device analytics, hourly/daily breakdowns, CSV export for ad verification
• Device telemetry — battery, storage, RAM, CPU, Wi-Fi signal strength and uptime reported by the players, plus both of a display's addresses: its local (LAN) IP as the player sees itself, and the public/WAN address the server saw it connect from. Wi-Fi network name is included where the platform allows it (Android 10+ needs an opt-in location permission — see Device Setup)
• Offline resilience — both web and Android players keep displaying cached content during server or internet outages (Android ContentCache, web player Service Worker); state syncs when connectivity returns
• Mobile-responsive — full management dashboard and landing page work on phones and tablets
• Workspaces — multi-tenant data model: organizations contain workspaces, workspaces contain devices/content/playlists/schedules; users can be members of multiple workspaces and switch via a dropdown in the sidebar
• Member roles — six-level hierarchy (platform_admin / org_owner / org_admin / workspace_admin / workspace_editor / workspace_viewer) gated at every API route
• Alerts — email notifications via Microsoft Graph when devices go offline; built-in spam protection (2h dedup, 24h long-offline cutoff, sequential send pattern); per-user opt-out via Settings → Account
• White-label — custom branding, colors, logo, favicon, CSS, and domain
• Content management — folder organization, remote URL content (no upload needed), YouTube embeds, video duration detection via ffprobe, automatic thumbnail generation, Unicode-safe filenames (NFC normalization + UTF-8 multipart decoding)
• Export/Import — v2 format with playlists, device groups, schedules, and optional media bundling (ZIP); backward-compatible v1 import with automatic playlist migration
• Device authentication — per-device tokens for secure WebSocket connections; devices authenticate on every reconnect
• Account management — in-app password change, profile editing, email-based password reset
• Security — JWT auth, bcrypt hashing, parameterized SQL, rate-limited endpoints, per-user ownership checks on all resources, ongoing auth/IDOR/XSS audits
• Built-in billing — Stripe integration for SaaS subscriptions (optional)
• Auto-update — OTA updates pushed to devices automatically
• Public REST API — scoped personal access tokens (read / write / full) over the same resources the dashboard uses, workspace-confined by construction. Documented as an OpenAPI 3.1 contract (docs/openapi.yaml) and browsable on any instance at /docs (served locally, no CDN, so it works air-gapped)
• Activity log — full audit trail of user and system actions

Architecture

Multi-tenancy model

Three nested primitives:

organizations (billing + branding container)
   workspaces  (resource scope: devices, content, playlists, schedules, walls, layouts, widgets, groups)
      members (users with a role on that workspace)

Every resource (device, content row, playlist, schedule, etc.) carries a workspace_id. Every API route filters by it. Cross-workspace access requires switching workspaces via the sidebar dropdown — there are no magic role-based "see everything" bypasses on individual resource routes.

Role hierarchy

Six roles, top wins:

Role	Scope	Cap
platform_admin	every workspace in the system	full read/write (via acting-as on workspaces they're not a direct member of)
org_owner	one organization	billing + delete + admin within all workspaces in the org
org_admin	one organization	admin within all workspaces in the org (no billing)
workspace_admin	one workspace	manage members, rename, full read/write
workspace_editor	one workspace	create/edit content, devices, playlists, schedules; no member changes
workspace_viewer	one workspace	read-only

Workspace switcher

Users who are members of more than one workspace see a dropdown in the sidebar header. Switching mints a fresh JWT with the new current_workspace_id claim and reloads the page. Platform admins see every workspace in the system.

Auto-migration on boot

Schema migrations run automatically the first time the server starts after a git pull. Self-hosters never need to run a manual migration command. On detecting a pre-multi-tenancy database, the server takes a timestamped snapshot (server/db/remote_display.pre-migration-<timestamp>.db), runs the Phase 1 migration (creates organizations / workspaces / workspace_members tables, backfills workspace_id on every resource, one auto-created Default workspace per existing user), then continues startup. If the migration fails the server prints the restore command and exits.

Data flow

• Android / web players → device-namespace WebSocket → server. Authenticated per-device with a long-lived device token. Each device joins a room keyed on its device_id.
• Admin dashboard → dashboard-namespace WebSocket → server. Authenticated with the user's JWT. Each socket joins one room per accessible workspace so outbound events (device status, screenshots, playback progress) only reach dashboards that should see them.
• Admin REST → /api/* HTTPS → Express → SQLite. Everything scoped by workspace_id from JWT current_workspace_id claim.
• Email → pluggable transport (EMAIL_TRANSPORT): Microsoft Graph sendMail via client-credentials OAuth (in-memory token cache) or SMTP via nodemailer. Sequential send pattern through alert backlogs to respect per-app concurrency limits.

Supported Platforms

Android TV, Fire TV, Raspberry Pi, Windows, ChromeOS, LG webOS, Samsung Tizen, BrightSign, and any device with a web browser.

Anything with a reasonably modern browser can be a display without installing anything: point it at /player. The native players add what a browser cannot: the Android APK gives you unattended boot, OTA self-update, remote power and touch injection, and a content cache that survives a reboot; the Tizen .wgt gives you an installed app that launches itself on the TV. Tizen does not self-update — new versions are installed the same way the first one was.

BrightSign runs the unmodified browser player (verified on Series 5 / Chromium 120) and needs no separate build. One caveat worth knowing before you rely on it: BrightSign's HTML widget does not always survive the page reload the player performs when you deploy new content, and may need a restart to come back. Treat it as working but less hands-off than the native players.

Self-Hosting

Requirements

• Node.js 20.6+ (the npm scripts use the built-in --env-file-if-exists flag, added in 20.6)
• Linux, macOS, or Windows
• SQLite (bundled via better-sqlite3; no separate install needed — npm install handles the native bindings)
• ffmpeg (optional but recommended) — powers video thumbnails and duration extraction (sudo apt-get install ffmpeg / brew install ffmpeg). Without it, videos upload and play fine but show no thumbnail in the content library. The Docker image includes it. The server logs a [MEDIA] line at startup telling you whether it was found, and backfills missing thumbnails automatically once ffmpeg appears after a restart.

Quick Start

git clone https://github.com/screentinker/screentinker.git
cd screentinker/server
npm install
SELF_HOSTED=true npm start

The server starts on port 3001 (HTTP). If SSL certificates are present in server/certs/, it starts on port 3443 (HTTPS) with automatic HTTP-to-HTTPS redirect. Open the URL shown in the startup banner. The first registered user gets full access with all features unlocked.

Schema migrations run automatically on first boot — no manual migration commands at any point in the lifecycle.

npm start is preferred over node server.js directly because the script invokes Node with --env-file-if-exists=.env so a server/.env file (gitignored) is loaded automatically for local dev.

Environment Variables

Variable	Description	Default
PORT	HTTP port	3001
HTTPS_PORT	HTTPS port (used when SSL certs are present)	3443
NODE_ENV	Runtime env (production enables Express production optimizations + stricter error handling)	(none)
SELF_HOSTED	First user gets all features unlocked	false
HIDE_BILLING	Hide the Subscription nav item + billing view; #/billing redirects to the dashboard (UI-only, opt-in)	false
DISABLE_REGISTRATION	Block new account creation (including OAuth auto-signup). First-user setup on an empty DB is still allowed.	false
DISABLE_HOMEPAGE	Redirect / to /app instead of serving the marketing landing page. For internal-only self-hosted deployments.	false
APP_URL	Your public URL (used for Stripe callbacks and invite-accept URLs in emailed invites)	(none)
JWT_SECRET	JWT signing key (auto-generated if not set)	(auto)
SSL_CERT	Path to SSL certificate	server/certs/cert.pem
SSL_KEY	Path to SSL private key	server/certs/key.pem
PING_INTERVAL	Socket.IO Engine.IO ping interval (ms). Raise for slow TV WebKits that miss pongs under decode load.	30000
PING_TIMEOUT	Socket.IO Engine.IO pong wait (ms). Lower = faster dead-socket detection; higher = more forgiving of laggy clients.	30000
HEARTBEAT_INTERVAL	App-level offline-checker frequency (ms). How often the server sweeps the device list looking for stale heartbeats.	10000
HEARTBEAT_TIMEOUT	How long without an app-level heartbeat (ms) before marking a device offline. Raise for slow/jittery networks.	45000
MAX_FILE_SIZE	Largest upload the server will accept. Bytes, or a suffix (2GB, 1500MB). A reverse proxy caps this independently — see below.	500MB
COMMAND_QUEUE_TTL_MS	How long the server holds commands and playlist-updates for a device that's offline at emit time (ms). Flushed in order on reconnect within this window; dropped past TTL.	30000
OTA_ALLOW_MANAGED_DEVICES	Let Android players self-update even when an MDM/DPC owns the device. Off by default — see below before enabling.	0

Android players under an MDM

By default a player stands down from self-updating when it detects that another device owner (an MDM/DPC such as an EMM agent) manages the panel. The reasoning is that on a managed device the install confirmation dialog cannot be reliably auto-dismissed, so it ends up sitting over customer content — and the MDM is normally the thing distributing packages anyway. Such a panel reports manual_update_required rather than going quiet, so it still shows up as needing attention.

Set OTA_ALLOW_MANAGED_DEVICES=1 if you run an MDM that does not distribute the player and you want ScreenTinker's OTA to own updates instead. The server then advertises allow_managed: true in /api/update/check and players stop standing down.

Two things to know before enabling it:

• It does not grant the ability to install silently. Unless the player is the device owner, or the MDM has delegated DELEGATION_PACKAGE_INSTALLATION to it, Android still raises a confirm dialog that somebody (or an accessibility service) has to accept. If installs are failing with an MDM present, delegating that scope is usually the real fix — not this flag.
• It is read by the player, not the server, so only players new enough to understand allow_managed honour it. Older players keep standing down regardless.

When a display will not update itself

OTA is per-display and can be turned off per display. If one is not taking an update, the order to check is:

1. Is OTA enabled for it? There is a per-display toggle; a display with it off will never self-update, by design.

2. Is it standing down for an MDM? It reports manual_update_required if so — see above.

3. Has it been retrying and failing? Retrying and telling you about it are two separate things, on purpose:

   • After 3 failed installs the display flags itself as needing attention in the dashboard. A human is demonstrably required by then, so it says so early rather than at the end.
   • It keeps retrying anyway, up to 40 attempts. Attempts after the first are close to free — the APK is downloaded and signature-checked once and then reused from cache, so retry number twelve pulls no bytes.
   • Past that it settles to about one attempt a day, indefinitely. It never gives up for good, and a new version clears the count — so a display stuck for a week still picks up the next release on its own.

   The flag is what to watch for. Silence is not the signal.

Force update — per display, or as a group command — deliberately ignores the back-off, the attempt count and the MDM stand-down, and tries straight away. It reports back either way, including "already up to date", so the button never just appears to do nothing. What it cannot do is invent permissions: if installs need a confirmation tap on that hardware, forcing still raises the dialog. It is the right button once you have fixed whatever was breaking the update.

Running a beta channel

By default an instance serves one APK to every display, at /download/apk. You can publish a second build alongside it and send it only to displays you choose:

1. Put the beta APK next to the stable one, as ScreenTinker-beta.apk (same locations as ScreenTinker.apk — /data/ in a container, or the install root).
2. Declare its version in a sidecar text file, ScreenTinker-beta.apk.version, containing just the version — e.g. 1.9.27-rc1. This is required. The server cannot read the version out of an APK cheaply, and advertising a version that does not match the bytes it serves is how update loops start, so a beta with no declared version is ignored entirely and opted-in displays keep getting the stable build.
3. Tick Accept pre-release builds on any display that should receive it.

Untick the box to move a display back to the release build — the server offers it the stable build even though it is technically "older" than the beta. Displays you never put on the channel are untouched by any of this.

Cut beta builds with the same versionCode as the stable release they branch from. Android refuses to install a lower versionCode, so a beta numbered above stable can be installed but never returned without uninstalling the app (which loses the display's pairing). Equal numbers install in both directions, which is what makes switching back work.

Deleting and re-pairing a display

A display's settings are keyed to the hardware, not to its row in the database. Delete a display and pair the same panel again and it comes back with its previous name, orientation, timezone, notes and assigned playlist already set — you do not have to configure it twice, and a panel that is physically hard to reach does not need a visit. (The playlist only returns if it still exists; a deleted one is not resurrected.)

Two consequences that are easy to misread:

• The old playlist reappearing is ScreenTinker restoring it, not a bug. If you deleted the display in order to clear it, change the playlist after re-pairing rather than before.
• A blocked display stays blocked, deliberately. Blocking is a security control, so it must not be defeatable by deleting the display and pairing again. Use Unblock — that clears the stored block as well as the live one. (Before 1.9.25, Unblock only cleared the live one and the block came back on the next re-pair; if you have a display that refuses to pair for no visible reason, unblock it once on this version.)

Raising the upload limit

MAX_FILE_SIZE sets what the application accepts. It is usually not the only limit, and it is the last one in the chain — so raising it on its own often changes nothing and the upload still fails with a 413:

• nginx (or any reverse proxy) caps the request body with client_max_body_size. The default is 1MB, and a typical signage deployment sets 500M. Raise it to match:

  client_max_body_size 2048M;   # must be >= MAX_FILE_SIZE


• Cloudflare caps uploads per plan (100MB on Free/Pro at the time of writing) and returns 413 at the edge, before your server is involved. Large uploads need a plan that allows them, or a route that bypasses the proxy.

If an upload fails and nothing appears in the server log, the request never reached the app — check the proxy first.

Optional Integrations

All integrations are optional. The app works fully without any of them.

AI Content Design (local or cloud)

The Content Designer can turn a prompt into a finished sign — layout + copy from an LLM, and optional background/foreground imagery from an image model. Each workspace brings its own OpenAI-compatible endpoints (cloud, or fully local and free via Ollama + stable-diffusion.cpp). See docs/local-ai-setup.md.

Stripe (Billing)

If you want to charge your users, plug in your own Stripe keys. Without them, all features are free for all users.

1. Create a Stripe account
2. Create products/prices for each plan in the Stripe dashboard
3. Set up a webhook endpoint pointing to https://yourdomain.com/api/stripe/webhook with these events:
   • checkout.session.completed
   • customer.subscription.updated
   • customer.subscription.deleted
   • invoice.payment_failed
4. Update the plans table in the SQLite DB with your Stripe price IDs:

   UPDATE plans SET stripe_price_monthly = 'price_xxx', stripe_price_yearly = 'price_yyy' WHERE id = 'starter';


5. Set the environment variables:

Variable	Description
STRIPE_SECRET_KEY	Your Stripe secret key (sk_live_... or sk_test_...)
STRIPE_WEBHOOK_SECRET	Webhook signing secret (whsec_...)
APP_URL	Your public URL (e.g. https://signage.yourcompany.com)

The default plans are: Free (2 devices), Starter (8 devices), Pro (25 devices), and Enterprise (unlimited). Edit the plans table to change pricing, limits, or add/remove tiers. In self-hosted mode, the first user gets Enterprise automatically.

Plans and comped accounts

Platform admins get a plan overview under Admin → Subscription Plans: every plan on the instance with how many accounts, organizations and displays are on each, so you can see what people actually use before changing a price or retiring a tier. It also flags accounts pointing at a plan that no longer exists, which otherwise surfaces only as odd entitlement behaviour.

A plan marked inactive disappears from the customer-facing pricing page but keeps working normally for anyone already on it. That is how you run a comped, beta or legacy tier without advertising it — put the account on the hidden plan and it simply gets those limits. The overview above deliberately lists hidden plans too (marked as such), because the previous behaviour was that a hidden plan was invisible to the operator as well as the customer.

Single sign-on (OpenID Connect)

Setting it up? docs/sso-setup.md is the step-by-step guide — Google and Microsoft console walkthroughs, per-organization SSO, account linking, and a table of every error code with its actual cause. The rest of this section is the reference.

Any OIDC provider works — Google, Microsoft/Entra, Okta, Auth0, Keycloak, Authentik, Zitadel — through one flow: Authorization Code with PKCE, run server-side. The browser never talks to the provider directly, so there is no SDK to load and no third-party script origin to allow in the CSP.

Every login is verified as an ID token: signature against the provider's published JWKS, iss exactly as discovered, aud (and azp) matching your client, exp, and a nonce this server generated for that specific login. An access token is never accepted as proof of identity.

Set the redirect URI at your provider to:

https://yourdomain.com/api/auth/oidc/<slug>/callback

Set APP_URL so that origin is pinned — the redirect URI must match your provider's registration exactly, and deriving it from the request Host would both break behind a second hostname and take its value from the caller.

Google and Microsoft need only the variables this README has always documented; their issuer is filled in for you and their slugs are google and microsoft:

Variable	Description
GOOGLE_CLIENT_ID	OAuth 2.0 client ID from Google Cloud Console
GOOGLE_CLIENT_SECRET	Optional — PKCE means a public client works
MICROSOFT_CLIENT_ID	Application (client) ID from the Azure portal
MICROSOFT_TENANT_ID	Your tenant GUID — required. common/organizations are refused
MICROSOFT_CLIENT_SECRET	Required in practice — register the redirect URI under the Web platform, which Entra treats as a confidential client. A SPA registration is rejected at the token endpoint, because this exchange runs server-side and sends no browser Origin

Register the redirect URI under Web, add the email optional claim under Token configuration → ID, and note that Entra ID v2 does not send email_verified — ScreenTinker treats a tenant-pinned Microsoft entry as vouching for the address rather than demanding a claim Microsoft never emits. An explicit email_verified: false is still refused, and an organization's own provider can never make that assumption.

⚠️ Multi-tenant Microsoft (common) is deliberately refused, and Microsoft sign-in stays disabled until you set a tenant GUID. Two reasons that point the same way. It cannot work: Microsoft's multi-tenant metadata advertises the literal template https://login.microsoftonline.com/{tenantid}/v2.0, so the issuer never matches and every login fails anyway. And the obvious fix is dangerous — accepting that template means accepting tokens from every Azure tenant, which is nOAuth: any tenant admin can set an arbitrary, unverified email on one of their own users and be issued a session as that address. Safe multi-tenant support needs per-tenant pinning (validate tid against an allowlist, key accounts on oid+tid rather than email) and is not implemented.

Any other provider is added by slug:

OIDC_PROVIDERS=okta,authentik
OIDC_OKTA_ISSUER=https://example.okta.com
OIDC_OKTA_CLIENT_ID=0oa...
OIDC_OKTA_NAME=Okta                      # optional button label
OIDC_OKTA_CLIENT_SECRET=...              # optional — PKCE means a public client works
OIDC_OKTA_SCOPES=openid email profile    # optional
OIDC_OKTA_ASSUME_EMAIL_VERIFIED=true     # only if the IdP verifies addresses but omits the claim

The issuer is the base URL whose /.well-known/openid-configuration describes the provider; endpoints and keys are discovered from it and cached.

Account rules. A provider must assert a verified email, because the whole account model keys on it. An SSO login never takes over an existing account that has a password — the owner signs in locally and links from Settings. If the provider's stable subject (sub) changes for an address, the login is refused rather than handing an account to a recycled mailbox.

An account established by one provider is not adopted by another. A per-organization provider may only claim an account that its own organization established, or a local account that has never set a password (an invited user signing in for the first time); anything else is refused with account_exists_other_provider. The earlier rule — "any account without a password may be re-pointed at whichever provider spoke last" — was safe only while the operator chose every provider, and became an account-takeover primitive the moment customers could add their own.

⚠️ TOTP is not prompted on an SSO login. Second-factor is the identity provider's job in this flow, matching the long-standing behaviour of the SSO and API-token paths.

Per-organization SSO (customer-configured)

The providers above are instance-wide — they belong to whoever runs the server and appear as buttons on the login page for everyone.

An organization can also bring its own identity provider, configured by an org owner or admin in Settings → Single sign-on. No environment variable or restart is involved.

A per-org provider is never listed publicly. It appears only when someone types an email address at one of that organization's verified domains, at which point the login page offers a generic "Continue with single sign-on" button. The domain lookup answers only whether that domain uses SSO and whether it is required — never a provider name or slug — so a guessed domain cannot confirm who a customer is, and the mapping back to a provider happens server-side on submit. Both endpoints are rate limited.

Instance-wide is the default; an organization overrides only its own verified domains. Type an address whose domain no organization has verified and you get the local password form plus every instance provider you configured. Type one that an organization has verified and its own button is added — and if that organization requires SSO, it becomes the only option.

Each provider gets a randomly generated redirect URI, shown in Settings, which the admin registers with their identity provider:

https://yourdomain.com/api/auth/oidc/<generated-slug>/callback

The slug is generated rather than chosen so two customers cannot collide on — or guess — each other's. A domain may be claimed by only one organization; a second claim is refused.

A customer bringing Microsoft/Entra registers a single-tenant application in their own directory and uses https://login.microsoftonline.com/<their-tenant-guid>/v2.0 as the issuer. Because Entra does not send email_verified, an organization's provider is trusted to assert addresses once it has verified a domain — the DNS proof is what stands in for the claim, and the provider is confined to those domains regardless. A provider that has verified nothing assumes nothing, and an explicit email_verified: false is refused whoever sends it.

⚠️ A provider may only authenticate emails inside the domains it has VERIFIED. An organization supplies its own issuer and client ID, so it controls that identity provider completely and could otherwise assert any address at all — including another company's, or an administrator's. Confining assertions to verified domains is what makes customer-configurable SSO safe to offer.

⚠️ Public email providers cannot be claimed. gmail.com, outlook.com, yahoo.com, icloud.com and the rest of the consumer mailboxes are refused (server/lib/public-email-domains.js). Claiming one would offer every Gmail user a "sign in with your organization" button pointing at one tenant's infrastructure — phishing launched from this product's own login page — and would let one account deny a public domain to everyone else.

Proving a domain

A claimed domain routes nobody and authenticates nobody until DNS proves the organization controls it. Typing a domain into a form reserves the name and nothing more.

Publish this record, then press Verify:

_screentinker-verify.example.com.  IN  TXT  "st-verify=<token>"

The token is unique per domain, so publishing one proof cannot be replayed to claim a second. A dedicated _-prefixed name is used rather than the apex, where a careless edit would sit alongside SPF and DMARC and break mail — and where a wildcard *.example.com could not be confused for a proof, since a wildcard answers with its own value and never with the token.

TXT is the only accepted form. A CNAME alternative would have to point at a wildcard zone this project operates, answering for every token ever issued; documenting one without running it would describe a check that can never pass.

⚠️ The proof name itself must not be a CNAME. A TXT lookup follows CNAMEs, and a wildcard *.example.com covers _screentinker-verify.example.com too — so a wildcard CNAME would let whoever controls its target prove the domain, turning an ordinary subdomain takeover into control of every @example.com login. A delegated proof name is refused, which is stricter than ACME's dns-01.

An unverified claim lapses after 8 hours, and lapsing RELEASES it. Pressing Verify on an expired claim does not reissue it in place — that renewed the clock, so one request per window held a domain forever. The claim is released, the domain becomes free for anyone else, and re-adding it is a new claim: new token, and the operator is notified again. A verified domain never expires; re-proving on a timer would log a customer out over a DNS edit made months afterwards. Squatting is not made impossible — it is made loud.

Deleting a provider releases its domains and returns its accounts to local sign-in, so the organization can re-claim its own domain and its people can recover by password reset. Both used to be stranded: a verified domain row outlived its provider and blocked that domain for everyone permanently, and its users could neither sign in nor reset.

Platform admins are emailed whenever a domain is claimed. Verification is what makes an unowned claim worthless; the notification is what makes an attempt visible. Nothing is ever sent to the claimed domain itself — that would let any tenant make this product email third parties.

⚠️ Instance-wide providers are exempt from all of the above. GOOGLE_CLIENT_ID, OIDC_* and friends are the operator's own configuration, are not domain-restricted, and require no verification. Domain proof exists because per-organization providers are supplied by CUSTOMERS.

Signing in through an organization's provider makes the user a member of that organization (org_member). Existing members keep whatever role they already have — logging in never promotes or demotes anyone. Client secrets are optional (PKCE), and are stored AES-256-GCM encrypted and never returned by the API.

Requiring single sign-on

An organization can turn off password sign-in for its verified domains, so its identity provider is the only way in — which is the point of buying SSO: the IdP holds the MFA, the conditional access and the instant removal of access, and a password box beside it is a way around all three.

Settings → Single sign-on → Require single sign-on. It needs at least one verified domain, so an organization cannot leave its own people with no way to sign in, and cannot switch off passwords for a domain it merely typed.

When it is on:

• the login page hides the password field for those domains rather than letting someone type a password that is going to be refused and then send them to reset it;
• POST /api/auth/login refuses with 403 sso_required — distinguishable from a wrong password, because the page must not tell a user to fix a credential that is not the problem;
• every other identity provider is refused too, including the instance's own Google or Microsoft. Those belong to the operator and are not domain-restricted, so leaving them available would be a side door straight past the customer's MFA — blocking passwords while leaving "Continue with Google" is not requiring single sign-on, it is renaming the bypass.

Turning it off is a request, not a switch. That direction re-opens password sign-in, so it is the direction an attacker who has taken an org admin would take, and it is also what a customer will demand at their worst moment — identity provider down, nobody can work — which is exactly when a self-service toggle gets flipped without thinking. The org admin files a request; a platform admin approves it, and nothing changes until they do.

The approval email deliberately carries no action link. A token that acts on its own would turn every forwarded, archived or auto-previewed copy of that message into a way to switch off a customer's single sign-on. The decision is made signed in, under Admin.

⚠️ platform_admin is exempt from enforcement, and that exemption is load-bearing. The operator is who approves removal. If the operator's own address sat at an SSO-only domain and that identity provider broke, nobody could sign in to approve anything and the instance would be bricked with no way out. It is the break-glass — it applies to the people running the server, never to a customer's own admins.

⚠️ This makes the approval queue an availability dependency. An organization whose IdP breaks is locked out until an operator acts. That is the intended trade — deliberate friction on the dangerous direction — but it should be a decision, not a surprise.

Dependency preflight on boot

Before anything else is loaded, the server checks that the packages this build declares are actually installed and that the native database module loads under the running Node. If either is wrong it repairs it (npm install --omit=dev, or npm rebuild better-sqlite3) and continues; if it cannot, it exits saying what to run rather than dying on a MODULE_NOT_FOUND naming a file.

scripts/upgrade.sh already installs dependencies, so this is not for the normal path. It is for the ways a box ends up with the wrong node_modules:

• rolling back to an older tag restores that tag's package.json but not its packages — and you are rolling back because something is already wrong;
• upgrading Node leaves better-sqlite3 compiled against the previous ABI, which fails in a way that reads like database corruption and is not.

Set ST_SKIP_DEP_PREFLIGHT=1 on an air-gapped host, or anywhere you manage node_modules yourself and do not want a boot reaching for the registry.

Email (Microsoft Graph or SMTP)

Email powers offline alerts, welcome/signup mail, admin notifications, and password reset. Two interchangeable transports are supported, selected by EMAIL_TRANSPORT:

Variable	Description	Default
EMAIL_TRANSPORT	graph (Microsoft Graph) or smtp (any mail server)	graph

Configure the variables for whichever transport you pick (below). If the selected transport is left blank, email is disabled and delivery is logged to stdout instead. If it is partially configured (some fields set, others missing), the server logs a clear [EMAIL] … MISCONFIGURED — missing: … error at startup.

Option A — Microsoft Graph (EMAIL_TRANSPORT=graph, default)

Microsoft Graph Mail.Send via the client-credentials flow. Best if you already run Microsoft 365 / Azure.

Variable	Description
GRAPH_TENANT_ID	Microsoft Azure AD tenant ID
GRAPH_CLIENT_ID	Azure AD app registration client ID
GRAPH_CLIENT_SECRET	Azure AD app registration client secret
GRAPH_SENDER_EMAIL	Mailbox to send from (must be a valid mailbox or alias in the tenant)
GRAPH_SENDER_NAME	Display name shown in the email From field (defaults to ScreenTinker)

Azure AD app setup:

1. Register a new app in Azure AD (single-tenant)
2. Under API permissions, add an Application permission: Microsoft Graph → Mail.Send
3. Click Grant admin consent for the tenant
4. Under Certificates & secrets, generate a new Client secret and capture the value (it is only shown once)
5. Capture the Directory (tenant) ID and Application (client) ID from the Overview page
6. Set the five env vars above in your deployment (systemd unit, .env file, etc.)

Option B — SMTP (EMAIL_TRANSPORT=smtp)

Send via any standard mail server (Postfix, Gmail, Mailgun, SendGrid, a corporate relay, …) using nodemailer. Ideal for self-hosters without an Azure/M365 setup.

Variable	Description	Default
SMTP_HOST	Mail server hostname (e.g. mail.example.com)	(required)
SMTP_PORT	Port — 587 for STARTTLS, 465 for implicit TLS	(required)
SMTP_SECURE	true = implicit TLS (465); false = STARTTLS (587)	false
SMTP_USER	Auth username. Omit (with SMTP_PASSWORD) for an unauthenticated relay	(none)
SMTP_PASSWORD	Auth password. Required if SMTP_USER is set	(none)
SMTP_FROM	From address — Name <addr@example.com> or addr@example.com	(required; falls back to SMTP_USER)

Example (Gmail app password):

EMAIL_TRANSPORT=smtp
SMTP_HOST=smtp.gmail.com
SMTP_PORT=587
SMTP_SECURE=false
SMTP_USER=you@gmail.com
SMTP_PASSWORD=your-app-password
SMTP_FROM=ScreenTinker <you@gmail.com>

The Docker image bundles nodemailer, so no extra steps are needed for a self-hosted container — just set the SMTP_* vars in your env_file / compose environment.

Local dev fallback: if the selected transport is unconfigured (e.g. no GRAPH_*, or no SMTP_*), sendEmail() short-circuits and logs [EMAIL] not configured - would send to ... to stdout instead of sending. The app keeps running normally; only delivery is suppressed. A minimal local-dev install with no mail access works fine — email-triggering features just won't deliver anything externally.

Dev safety allow-list:

Variable	Description
GRAPH_DEV_RESTRICT_TO	Comma-separated allow-list of recipient emails (applies to both transports). When set, sends to addresses not in the list are suppressed (logged but never delivered).

Use this in local dev when running against a fresh production database clone to prevent accidental emails to real users. Leave it unset in production so emails flow to everyone normally.

Alert spam protections (also live, no configuration needed):

• 2-hour dedup window per (alert-type, target-id) pair — the same device won't trigger repeated alerts within two hours
• 24-hour long-offline cutoff — devices that have been offline for more than 24 hours stop generating alerts (the user already knows or the device is abandoned; further alerts are noise)
• Sequential send pattern through the offline-alert backlog — avoids Graph's per-app concurrent-send throttling (HTTP 429 ApplicationThrottled)
• Per-user opt-out via the email_alerts toggle in Settings → Account; respects user preference before any Graph call

Running one day to day? docs/operations.md is the runbook — deploy and rollback for both shapes, how to verify a deploy actually took, the served-APK rules, and the traps that have cost real time.

Production Deployment

For production, put the app behind a reverse proxy (nginx, Caddy, etc.) with SSL:

# Create a dedicated user
sudo useradd -r -s /bin/false screentinker

# Copy the app
sudo cp -r . /opt/screentinker
sudo chown -R screentinker:screentinker /opt/screentinker

# Install dependencies (ffmpeg is for video thumbnails + durations — see Requirements)
sudo apt-get install -y ffmpeg
cd /opt/screentinker/server && npm install --production

# Create a systemd service
sudo cat > /etc/systemd/system/screentinker.service << 'EOF'
[Unit]
Description=ScreenTinker
After=network.target

[Service]
Type=simple
User=screentinker
WorkingDirectory=/opt/screentinker/server
ExecStart=/usr/bin/node server.js
Restart=always
Environment=PORT=3001
Environment=NODE_ENV=production
Environment=SELF_HOSTED=true
# Lock down an internal / provisioned-only instance (all accounts created by your
# team). DISABLE_REGISTRATION closes self-service signup — first-user setup on an
# empty DB is still allowed, and the login page hides its "Create account" button
# to match. DISABLE_HOMEPAGE sends `/` straight to the app instead of the
# marketing landing page.
# Environment=DISABLE_REGISTRATION=true
# Environment=DISABLE_HOMEPAGE=true
# Environment=APP_URL=https://signage.yourcompany.com
# Environment=STRIPE_SECRET_KEY=sk_live_...
# Environment=STRIPE_WEBHOOK_SECRET=whsec_...
# Email alerts via Microsoft Graph - see Email Alerts section above for setup
# Environment=GRAPH_TENANT_ID=...
# Environment=GRAPH_CLIENT_ID=...
# Environment=GRAPH_CLIENT_SECRET=...
# Environment=GRAPH_SENDER_EMAIL=support@yourcompany.com
# Environment=GRAPH_SENDER_NAME=Your Brand

[Install]
WantedBy=multi-user.target
EOF

sudo systemctl enable --now screentinker

Nginx Example

server {
    listen 80;
    server_name signage.yourcompany.com;
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl http2;
    server_name signage.yourcompany.com;

    ssl_certificate /path/to/cert.pem;
    ssl_certificate_key /path/to/key.pem;

    client_max_body_size 500M;

    location / {
        proxy_pass http://127.0.0.1:3001;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_read_timeout 86400;
    }
}

Don't add security headers at the proxy

The app already sets X-Frame-Options, Strict-Transport-Security, Content-Security-Policy, X-Content-Type-Options, etc. via helmet, and manages them per route: widget/kiosk renders and the device preview deliberately remove or relax X-Frame-Options so they can be framed, while the dashboard keeps the strict policy.

A proxy-level header block (nginx add_header X-Frame-Options DENY;, a Caddy header { ... } snippet, or a "security headers" preset) adds a second copy of these headers on top of the app's. Browsers treat conflicting duplicate X-Frame-Options values as deny, which breaks the dashboard's device Preview (a same-origin iframe of /player) and widget previews with console errors like:

Refused to display 'https://…' in a frame because it set multiple
'X-Frame-Options' headers with conflicting values ('DENY, SAMEORIGIN').
Falling back to 'deny'.

Let the proxy handle TLS, compression, and body-size limits only, and leave security headers to the app.

Updating

To update a running instance to the latest version:

cd /opt/screentinker

# Upgrade to the latest tagged release. Backs up the db (a .backup snapshot under
# ./backups), checks out the tag, runs npm ci --omit=dev, restarts the service,
# and reports the running version.
scripts/upgrade.sh

# ...or pin a specific release:
scripts/upgrade.sh v1.8.0

Set SERVICE_NAME if your systemd unit is not named screentinker.

If you deployed without git, initialize it once so upgrade.sh can resolve tags:

cd /opt/screentinker
git init
git remote add origin https://github.com/screentinker/screentinker.git
git fetch origin --tags
git checkout -f main
cd server && npm install --production
sudo systemctl restart screentinker

Track bleeding edge (main) instead of tagged releases - newest code, less tested:

cd /opt/screentinker && git checkout main && git pull origin main
cd server && npm install --production && sudo systemctl restart screentinker

Your database, uploads, and configuration are preserved — only code files are updated.

Schema migrations run automatically. No manual migration commands at any point. On detecting a database that hasn't been through Phase 1 multi-tenancy migration yet, the server takes a timestamped snapshot first (server/db/remote_display.pre-migration-<timestamp>.db) and only continues startup once migration commits cleanly. If migration fails, the server logs the snapshot's path and exits — restore it with cp and investigate before retrying.

Backups

The SQLite database is at server/db/remote_display.db and uploaded content is in server/uploads/. For a one-off DB copy (safe while the server runs):

sqlite3 server/db/remote_display.db ".backup /path/to/backup.db"

Recommended: nightly automated backups via scripts/backup.sh. It takes an atomic DB snapshot plus a hard-linked, point-in-time copy of your content (durable images/videos; ephemeral per-device screenshots are excluded), with daily + monthly retention and an error log. Add a cron entry:

# as root (or your service user) — adjust the path to your install
0 3 * * * /opt/screentinker/scripts/backup.sh

Override defaults with env vars if your layout differs: SCREENTINKER_DIR (default /opt/screentinker), BACKUP_DIR, DB, UPLOADS, DAILY_KEEP (7), MONTHLY_KEEP (12), DB_KEEP_DAYS (30). Backups land in $BACKUP_DIR (remote_display-<ts>.db, content-latest/, content-<ts>/, content-monthly-<YYYYMM>/) and each run appends to $BACKUP_DIR/backup.log.

Admin Recovery

Locked out? Run this on the server to get a temporary admin token (1 hour):

node scripts/reset-admin.js

Forcing an update on one display

A display whose periodic update checker isn't firing won't pull a new APK on its own, and putting it on the beta channel alone won't reach it either. This sends the same forced check the dashboard's force-update button sends — it ignores the backoff cap and the MDM stand-down:

node scripts/force-update.js --list          # displays online right now
node scripts/force-update.js <id-or-prefix>  # force a check on one display
node scripts/force-update.js <id> --dry-run  # prove auth/handshake, send nothing

Run it on the server (it needs the database and JWT_SECRET, and mints a short-lived platform_admin token). On a display that isn't device-owner provisioned the install raises a confirm dialog over whatever is on screen and leaves it there until someone accepts, so aim it at one display when a person can see it. Updating preserves runtime permissions; only uninstalling clears them.

Building the Android APK

The Android player app is in the android/ directory. To build it:

cd android

# Set your keystore credentials (or generate a new keystore)
export KEYSTORE_PASSWORD=your_password
export KEY_ALIAS=your_alias
export KEY_PASSWORD=your_password

# Build the APK
./gradlew assembleDebug

The APK will be at android/app/build/outputs/apk/debug/app-debug.apk. Copy it to server/ as ScreenTinker.apk to serve it from /download/apk:

cp android/app/build/outputs/apk/debug/app-debug.apk ScreenTinker.apk

Release builds & MDM signage (#81): ./gradlew assembleRelease is automatically re-signed to carry a v1 (JAR) signature alongside v2/v3 (the resignReleaseV1 task in app/build.gradle.kts). At minSdk 26 the Gradle plugin omits v1, and some MDM-managed commercial displays (e.g. MAXHUB/Pivot) strip a v2-only APK on reboot — screens that power-cycle nightly then lose the app. v1+v2+v3 installs everywhere from API 19 to the latest Android. (enableV1Signing = true alone does not work at minSdk ≥ 24.)

To generate a new signing keystore:

keytool -genkey -v -keystore android/release-key.jks -keyalg RSA -keysize 2048 -validity 10000 -alias your_alias

Requirements: Java 17+, Android SDK (API 34).

Device Setup

1. Register at your ScreenTinker instance
2. Go to Displays and click Add Display
3. Install the ScreenTinker app on your device:
   • Android TV / tablets: Download the APK from your instance (/download/apk) or build it from source (see above)
   • Raspberry Pi: curl -sSL https://your-instance/scripts/raspberry-pi-setup.sh | sudo bash (see Raspberry Pi notes)
   • Debian 13 (headless): curl -sSL https://your-instance/scripts/debian-13-setup.sh | sudo bash
   • Windows: Run the setup script from scripts/windows-setup.bat
   • Samsung Tizen TV / signage: point the TV's URL Launcher (or browser) at https://your-instance/player - no signing needed. For an installed native app, see tizen/README.md
   • Any browser: Open https://your-instance/player in kiosk/fullscreen mode
4. Enter the pairing code shown on the device

Raspberry Pi notes

Run it with sudo. The script installs packages and writes systemd units, so it refuses to run otherwise. Piping is fine — prompts are read from your terminal, not from the pipe:

curl -sSL https://your-instance/scripts/raspberry-pi-setup.sh | sudo bash

To pick Player-Only without being asked:

curl -sSL https://your-instance/scripts/raspberry-pi-setup.sh | sudo bash -s -- --player-only https://your-server

Pi 5 / Bookworm runs Wayland by default. The kiosk launcher detects the session and does the right thing on either: xset/unclutter are X11-only and are skipped on Wayland (where they are no-ops that log an error and silently do nothing), Chromium is given --ozone-platform=wayland, and --password-store=basic stops it asking for a keyring password no kiosk has anyone to answer.

Blanking and cursor-hiding belong to the compositor on Wayland. The launcher calls wlopm when it is present; if your image does not ship it, set the equivalent in your compositor's config (~/.config/wayfire.ini [idle] for wayfire, or the labwc equivalent).

A white page on every boot but the first was Chromium restoring a session it believed crashed — a kiosk is killed by shutdown and never exits cleanly, so it came back with a restore surface on top of the player. The launcher now clears the stored session as well as the clean-exit flag.

Read-only root (Overlay FS) on a Pi that loses power

Worth enabling for Player-Only installs, where the Pi holds no state you cannot recreate: the overlay absorbs writes into RAM, so a power cut cannot corrupt the card and the flash does not wear out. Re-run the setup script (or raspi-config → Performance → Overlay File System) after the install, and remember that pairing is stored on the device — re-pair once with the overlay disabled, then enable it, or the pairing is lost at every reboot.

Do not enable it on an All-in-One install without moving the data first. That Pi is the server: the SQLite database, uploaded media and the JWT secret live under /opt/screentinker, and an overlay discards every write at reboot — so content you upload and displays you pair vanish on the next power cycle. If you want both, put DATA_DIR on a writable partition or an external drive that is excluded from the overlay, and confirm the database file is genuinely outside it before trusting the setup.

On the Android player, the setup screen lists the permissions it wants and lets you revisit any of them later — each row stays visible once granted and turns into Manage, so you can check or revoke what you gave it rather than having the option disappear.

One of those rows is optional and off by default: granting location lets the player report the Wi-Fi network name for the display. Android 10 and later will not reveal the SSID without it. Nothing else changes if you skip it — the display works identically and still reports signal strength, and the dashboard says the network name needs that permission rather than showing a blank.

One playlist per display, and how to run more. A display has a single playlist at a time. To rotate between several, use Scheduling — "Playlist A 9am-5pm, Playlist B evenings", or different playlists on different days — and the display switches on its own, offline included, once the schedule has reached it.

Troubleshooting a player (stuck on "Connecting to server", re-pointing a device to a different server, or connecting adb over Wi-Fi): see docs/android-troubleshooting.md.

For Developers

Working on ScreenTinker itself:

git clone https://github.com/screentinker/screentinker.git
cd screentinker/server
npm install
npm start          # starts in dev with --env-file-if-exists=.env
# or:
npm run dev        # same as start, plus --watch for auto-restart

.env file (gitignored): create server/.env for local configuration. Anything documented in the env var tables above works. Common starting set:

SELF_HOSTED=true
APP_URL=https://localhost:3443
# Optional: Microsoft Graph email config for testing real delivery
# GRAPH_TENANT_ID=...
# GRAPH_CLIENT_ID=...
# GRAPH_CLIENT_SECRET=...
# GRAPH_SENDER_EMAIL=you@yourcompany.com
# Optional: dev safety - only let these recipient emails through to Graph
# GRAPH_DEV_RESTRICT_TO=you@yourcompany.com,colleague@yourcompany.com

No M365 access? That's fine. With GRAPH_* env vars unset, sendEmail() short-circuits and logs [EMAIL] not configured - would send to ... to stdout. Everything else runs normally; only outbound email is suppressed. Useful for backend work that touches the email path without setting up an Azure app.

Running against a fresh prod DB clone? Set GRAPH_DEV_RESTRICT_TO=your-email@example.com to keep accidental sends from reaching real users in the cloned database. Sends to anyone outside the list are logged but never posted to Graph.

Reporting issues: GitHub Issues for bugs and feature requests, or drop into Discord for quick questions and feedback.

Contributions welcome. Fork → branch → PR. There are no formal style guides yet beyond what you can pick up from reading the existing code. Tests aren't required but smoke-test against your local server before opening a PR.

Project Structure

server/           Node.js/Express backend
  config.js       Configuration and environment variables
  server.js       Main entry point
  db/             SQLite database, schema, and migrations
  routes/         API route handlers (devices, playlists, groups, schedules, etc.)
  middleware/     Auth (JWT + device tokens), rate limiting, file upload, sanitization
  services/       Background services (heartbeat, scheduler, alerts, activity logging)
  ws/             WebSocket handlers (device namespace + dashboard namespace)
  player/         Web-based display player
frontend/         Static SPA dashboard
  js/views/       View components (dashboard, playlists, groups, schedules, etc.)
  js/utils.js     Shared utilities (HTML escaping)
  css/            Stylesheets
  legal/          Terms, privacy, licenses
android/          Android TV/tablet player app (Kotlin, ExoPlayer)
scripts/          Device setup scripts + admin recovery

Tech Stack

• Backend: Node.js 20.6+, Express, Socket.IO, SQLite (better-sqlite3)
• Frontend: Vanilla JS SPA (no framework, no build step), ES modules, Service Worker for offline support
• Android: Kotlin, ExoPlayer, Socket.IO client
• Auth: JWT with bcrypt, Google/Microsoft OAuth (optional)
• Email: Microsoft Graph via @azure/msal-node client-credentials (optional)
• Payments: Stripe (optional)
• Data model: multi-tenant — organizations contain workspaces contain resources; six-level role hierarchy gated server-side at every API route

Support

ScreenTinker is free and MIT licensed, and it stays that way. If it's useful to you and you want to help keep development going, you can chip in:

• ⭐ Star the repo, honestly this helps more than you'd think
• 💬 Report bugs or ideas in Discord or issues
• ☕ Donate via Wise (ByteTinker LLC)

GitHub Sponsors integration is also planned. Direct contact: dan@bytetinker.net or via Discord.

License

MIT
